Receiver
-
Transmitter
-
Proximity Sensor (PS)
-
| Part No. |
Description | Vout (V) | Max. Pout(W) | Reverse Charging(W) | Package |
| MT5705 |
Rx | 3.5V~5V | 5W | - | QFN32（4×4） |
| MT5706 |
Rx | 3.5V~12V | 15W | 5W | WLCSP |
| MT5727H |
RTx | 3.5V~20V | 30W | 10W | WLCSP |
-
| Part No. |
Description | Vin (V) | Max. Pout(W) | Package |
| MT5805 |
Tx | 3.5V~20V | 15W | FCQFN（3×4） |
| MT5811 |
Tx | 3.5V~16V | 15W | QFN48（6×6） |
-
| Part No. |
Type | Operating Voltage | ALS Bits | PS Bits | PS Operating Distance | LED | Package |
| MT3101 |
PS | 1.7V~3.6V | - | 12bits | <10cm | 940nm VCSEL | OLGA-8 |
| MT3102 |
PS | 1.6V~2.0V | - | 16bits | <4cm | 940nm VCSEL | OLGA6 |
